Fujifilm X-T5 – FULL SPECS and PRICE LEAKED – Same EVF of X-T4 and More Details

Share

On an anonymous Japanese forum, Nokishita leaked the full specs of the Fujifilm X-T5.

Nokishita also says that the specs sheet might be in the process to be re-written from, so not everything might be accurate.

At the bottom of the article we list the full specs. But before that, just a few highlights.

  • X-T5 Body (Black/Silver) $1699/1699pound
  • X-T5 XF16-80mm Kit (Black/Silver) $2199 / 2149pound
  • X-T5 XF18-55mm Kit (Black/Silver) $2099/2049pound

We also see that it will be smaller and lighter than the X-T4. And without battery, it will also be lighter than the X-T3.

  • X-T3 weight:
    – 489 g w/o battery + SD Cards
    – 539 g with battery + SD Cards
  • X-T4 weight:
    – 526 g w/o battery + SD Cards
    – 607 g with battery + SD Cards
  • X-T5 weight:
    – 476 g w/o battery + SD Cards
    – 557 g with battery + SD Cards
  • X-T3 size: 132.5 x 92.8 x 58.8 mm
  • X-T4 size: 134.6 x 92.8 x 63.8 mm
  • X-T5 size: 129.5 x 91 x 63.8mm

In terms of the EVF, the Fujifilm X-T5 will use the same EVF of the Fujifilm X-T4.

Fujifilm X-T5 – Full Specs

Number Of Effective Pixels:
– 40.2 millions pixels
Image Sensor:
– 23.5mm x 15.6mm (APS-C) X-Trans CMOS 5 HR with primary color filter
Sensor Cleaning:
– System Ultra Sonic Vibration
File Format (Still)
– JPEG-Exif Ver.2.32, HEIF-4:2:2 10bit, RAW-14bit RAW (RAF original format), TIFF-8bit / 16bit RGB (In-camera Raw Conversion Only)
Number Of Recorded Pixels
– L: (3:2) 7728 x 5152 (16:9) 7728 x 4344 (1:1) 5152 x 5152 M: (3:2) 5472 x 3648 (16:9) 5472 x 3080 (1:1) 3648 x 3648 S: (3:2) 3888 x 2592 (16:9) 3888 x 2184(1:1) 2592 x 2592
Lens Mount
– FUJIFILM X mount
Sensitivity Standard Output
– Still: Auto1/ auto2/ auto3/ ISO125-12800 (1/3 Step)
– Movie: Auto/ ISO125-12800 (1/3 Step)
Sensitivity Extended Output
– Still: ISO80/I SO100/ ISO25600/ ISO51200
– movie: ISO25600
Exposure Control
– TTL 256-zone metering/ Multi/ Spot/Average/ Center Weighted
Exposure Mode
– P (Program AE)/ A (Aperture Priority AE)/ S (Shutter Speed Priority AE)/ M (Manual Exposure)
Exposure Compensation
– STILL: -5.0EV-+5.0EV (1/3EV step)/ MOVIE: -2.0EV-+2.0EV (1/3EV step)
Image Stabilizer Mechanism
– Image sensor shift mechanism with 5-axis compensation
Image Stabilizer Compensation Effect
– Up to 7.0 stops (based on CIPA standard). Pitch/yaw shake only, with XF35mmF1.4 R lens attached.
Digital Image Stabilization
– Yes, movie mode only
Image Stabilizer Is Mode Boost
– Yes, movie mode only
Shutter Type
– Focal Plane Shutter
Shutter Speed Mechanical Shutter
– P mode: 30 sec to 1/8000
– A mode: 30sec to 1/8000
– S/M mode: 15min to 1/8000
– Bulb mode: up to 60min
Shutter Speed Electronic Shutter
– P mode: 30 sec to 1/180000
– A mode: 30sec to 1/180000 S/M mode: 15min to 1/180000 Bulb mode: 1sec Fixed
Electronic Front Curtain Shutter Speed
– P mode: 30 sec to 1/8000
– A mode: 30sec to 1/8000
– S/M mode: 15min to 1/8000
– Bulb mode: up to 60min
Mechanical + Electronic Shutter Speed
– P mode: 30 sec to 1/180000
– A mode: 30sec to 1/180000
– S/M mode: 15min to 1/180000
– Bulb mode: up to 60min
E-Front + Mechanical Shutter Speed
– P mode: 30 sec to 1/8000
– A mode: 30sec to 1/8000
– S/M mode: 15min to 1/8000
– Bulb mode: up to 60min
E-Front+Mechanical+Electronic Shutter
– P mode: 30 sec to 1/180000
– A mode: 30sec to 1/180000
– S/M mode: 15min to 1/180000
– Bulb mode: 1sec Fixed Shutter Speed
Shutter Speed Movie
– 6.2K: 1/8000 to 1/24
– DCI 4K/4K: 1/8000 to 1/4 sec.
– FHD: 1/8000 to 1/4 sec.
Synchronized Shutter Speed For Flash
– Mechanical Shutter: 1/250sec. or slower
– Electronic Shutter: 1/125sec. or slower
Continuous Shooting
– Electronic Shutter Approx. 20fps (1.29x Crop) (JPEG: 168 frames ,Compressed RAW: 72, Lossless Compressed RAW 41, Uncompressed RAW: 37 frames, Uncompressed RAW +JPEG: 23 frames)
– Electronic Shutter Approx. 13fps (1.29x Crop) (JPEG: 1000+frames ,Compressed RAW: 104, Lossless Compressed RAW: 53, Uncompressed RAW: 23 frames, Compressed RAW + JPEG: 56, Lossless compressed RAW + JPEG: 44, Uncompressed RAW + JPEG: 23)
– Electronic Shutter Approx. 10fps (1.29x Crop) (JPEG: 1000+ frames ,Compressed RAW: 1000+, Lossless Compressed RAW 70, Uncompressed RAW: 25 frames, Compressed RAW +JPEG: 72 frames, Lossless compressed RAW + JPEG: 53 frames, Uncompressed RAW + JPEG: 23 frames)
– Mechanical Shutter Approx. 15fps (JPEG: 119frames ,Compressed RAW: 39 frames, Lossless Compressed RAW 22 frames, Uncompressed RAW: 19 frames, Compressed RAW + JPEG 27 frames)
– Mechanical Shutter Approx. 10fps (JPEG: 1000+ frames ,Compressed RAW: 56 frames, Lossless Compressed RAW 29 frames, Uncompressed RAW: 19 frames, Compressed RAW + JPEG: 34 frames)
– Mechanical Shutter Approx. 7.0fps (JPEG: 1000+ frames ,Compressed RAW: 1000+ frames, Lossless Compressed RAW 33 frames, Uncompressed RAW: 20 frames, Compressed RAW + JPEG: 45 frames, Lossless compressed RAW + JPEG: 22 frames, Uncompressed RAW + JPEG: 20 frames)
– Electronic Shutter Approx. 20fps (1.29x Crop) (While half press 20 frames ,After full press 140 frames)
– Electronic Shutter Approx. 13fps (1.29x Crop) (While half press 13 frames ,After full press 300 frames,)
– Electronic Shutter Approx. 10fps (1.29x Crop) (While half press 10 frames ,After full press 370 frames,)
– Electronic Shutter Approx. 13fps (While half press 13 frames ,After full press 70 frames,)
AE Bracketing
– AE Bracketing (Frames: 2, 3, 5, 7, 9 Step: by 1/3EV step, up to +/-3EV steps)
– Film simulation bracketing (Any 3 types of film simulation selectable)
– Dynamic Range Bracketing (100%, 200%, 400%)
Focus Mode
– Single AF/ Continuous AF/ MF
Focus Type
– Intelligent Hybrid AF (TTL contrast AF / TTL phase detection AF)
Focus Low-Light Performance
– Contrast: -4.0EV
– Phase Detection: -7.0EV
AF Frame Selection
– Single point AF: 13 x9/ 25 x17 (Changeable size of AF frame) Zone AF: 3 x3/ 5 x5/ 7 x7 from 117 areas on 13 x9 grid Wide/Tracking AF AF-S: Wide/ AF-C: Tracking
All
White Balance
– Auto (White Priority, Auto, Ambience Priority)/ Custom1 – 3/ Color Temperature Selection (2500k-10000k)/ Preset Daylight, Shade, Fluorescent Light-1, Fluorescent Light-2, Fluorescent Light-3, Incandescent Light, Underwater
Self-Timer
– 10sec./2sec.
Interval Timer Shooting
– Yes (Setting : Interval, Number of shots, Starting time, Interval timer shooting exposure smoothing)
Flash
– EF-X8 Guide Number approx. 11 (ISO200 m) / approx. 8 (ISO100 m)
Flash Sync Mode
– EF-X8: 1st Curtain/ 2nd Curtain
– Shoe Mount Flash: 1st Curtain/ 2nd Curtain AUTO FP (HSS) Synchronized terminal: 1st Curtain/ 2nd Curtain.

Flash Mode
– TTL (TTL Auto / Standard / Slow Sync. ) / Manual / Commander / Off Shoe Mount Flash TTL (TTL Auto) / Standard / Slow Sync. ) / Manual / Multi
Hot Shoe
– Yes (Dedicated TTL Flash compatible)
Viewfinder EVF
0.5 inch approx. 3.69 million dots OLED Color Viewfinder
Coverage of viewing area vs. capturing area: approx. 100%
Eyepoint: approx. 24mm (from the Rear End of the camera’s Eyepiece)
Diopter adjustment: -5-+3m-1
Magnification: 0.80 x with 50mm lens (35mm equivalent) at infinity and Diopter set to -1.0m-1
Diagonal angle of view: approx. 40 Degree (Horizontal angle of view: approx. 32 Degree ) Built-in eye sensor
LCD Monitor
3.0 inch Tilt-Type (Three Direction) Touch Screen Color LCD Monitor
Aspect Ratio 3:2
Resolution: Approx. 1.84 million dots
Touch Screen Shooting Mode
Shooting, AF, Focus Area, OFF, Double Tap Setting (ON/OFF), Touch Function Setting (ON/OFF), EVF Touch Screen Area Setting
Touch Screen Playback Mode
Swipe, Pinch-in / Pinch-out, Double-tap, Drag
File Format (Movie)
HEVC/ H.265: Audio: Linear PCM / Stereo sound (24bit / 48KHz sampling) MPEG-4, AVC/ H.264: Audio: Linear PCM / Stereo sound (24bit / 48KHz sampling)
MP4, MPEG-4, AVC/ H.264: Audio: AAC
Movie Compression
All Intra/Long-GOP
File Size / Frame Rate / Recording Time
6.2K (16:9) – 6240 x3150: 29.97p/ 25p/ 24p/ 23.98p 360Mbps/ 200Mbps/ 100Mbps/ 50Mbps

DCI 4K (17:9) – 4096 x2160: 59.94p/ 50p/ 29.97p/ 25p/ 24p/ 23.98p 360Mbps/ 200Mbps/100Mbps/50Mbps

4K (16:9) – 3840 x2160: 59.94p/ 50p/ 29.97p/ 25p/ 24p/ 23.98p 720Mbps/ 360Mbps/ 200Mbps/ 100Mbps/ 50Mbps

Full HD (17:9) -2048 x1080: 59.94p/ 50p/ 29.97p/ 25p/ 24p/ 23.98p 360Mbps/ 200Mbps/ 100Mbps/ 50Mbps

Full HD (16:9) – 1920 x1080: 59.94p/ 50p/ 29.97p/ 25p/ 24p/ 23.98p 360Mbps/ 200Mbps/ 100Mbps/ 50Mbps

Full HD High speed rec. (17:9) – 2048×1080: 240p/200p/ 120p/ 100p 360Mbps(recording)/ 200Mbps(recording)

Full HD High speed rec. (16:9) – 1920×1080: 240p/200p/ 120p/
100p/360Mbps(recording)/ 200Mbps(recording)

Film Simulation Mode
19 modes (PROVIA/Standard, Velvia/Vivid, ASTIA/Soft, Classic Chrome, PRO Neg.Hi, PRO Neg.Std, Classic Neg., Nostalgic Neg., ETERNA Cinema, ETERNA BLEACH BYPASS, ACROS, ACROS + Ye Filter, ACROS + R Filter ACROS + G Filter, Black & White, Black & White + Ye Filter, Black & White + R Filter, Black & White + G Filter, Sepia)
Clarity Setting
+/-5 steps
Monochromatic Color
 Yes
Grain Effect
Roughness Strong, Weak, Off, Size Large, Small
Color Chrome Effect
Strong, Weak, Off
Color Chrome Blue
 Strong, Weak, Off
Smooth Skin Effect
Strong, Weak, Off

Dynamic Range Setting
AUTO, 100%, 200%, 400%
ISO restriction (DR100%: No limit, DR200%: ISO320 or more, DR400%: ISO640 or more)
Dynamic Range Setting (Movie)
100%, 200%, 400%
ISO restriction (DR100%: No limit, DR200%: ISO320 or more, DR400%:
ISO640 or more)
Advanced Filter
Toy camera
Miniature
Pop color
High-key
Low-key
Dynamic tone
Soft focus
Partial color (Red / Orange / Yellow / Green / Blue / Purple)
Wireless Transmitter Standard
IEEE802.11a/b/g/n/ac (standard wireless protocol)
Wireless Transmitter Encryption
WEP/WPA/WPA2 mixed mode
Wireless Transmitter Access Mode
Infrastructure
Bluetooth Standard
Bluetooth Ver. 4.2 (Bluetooth low energy)
Bluetooth Operating Frequency
2402 – 2480MHz
Terminal – Digital Interface
USB Type-C (USB3.2 Gen2x1)
Terminal – Hdmi Output
HDMI connector (Type D)
Terminal – Others
3.5mm, stereo mini connector (Microphone), 2.5mm, Remote Release Connector, Hot shoe, Synchronized terminal
Power Supply
NP-W235 Li-ion battery (included)

Battery Life For Still Images
Economy Mode Approx. 740 frames, Normal Mode Approx. 580 frames
Actual Battery Life For Movie Capture
 6.2K Approx. 90min. (29.97p)
4K Approx. 80min. (59.94p)
Full HD Approx. 90min. (59.94p) F
ull HD Approx. 100min. (120P)
Continuance Battery Life
6.2K Approx. 130min. (29.97p)
4K Approx. 130min. (59.94p)
Full HD Approx. 150min. (59.94p) (For Movie Capture)
Operating Temperature
-10 Degree C-40 Degree C
Operating Humidity
10% – 80% (no condensation)
Starting Up Period
 Approx. 0.49sec.
Battery Info
Required, included
Battery Material
 Lithium ion
Battery Type
NP-W235
Battery Quantity
 1
Dimensions (W x H x D)
129.5 x 91 x 63.8mm
Minimum Depth
 37.9mm
Weight
Including battery and memory card: 557g (Approx.) Excluding battery and SD memory card: 476g (Approx.)

via Nokishita via digicame-info
